Toro OEM 98-7913 Anti-Scalp Wheel Spacer Fits Toro Late Titan HD (1500, 2000, 2500) Models – Late/Current 60″ Grandstand Standard – Current 72″ Grandstand HDX – Late/Current Z Master Models and More…

Description

Toro OEM 98 7913 (Metal) Anti-Scalp Wheel Spacer Fits on the Non-Molded Flange Side of the Anti-Scalp Wheel and is Often Used with a Two Spacer/One Bolt System. This Spacer System is Often Used on Models that Require the Anti-Scalp Wheel to Be Installed inside a Dual Bracket System with Retaining Ears on Both Sides of the Anti-Scalp. Toro 98 7913 Spacer Spaces the Non-Molded Flange Side of the Anti-Scalp Wheel Away from the Retaining Ear, eliminating it From Rubbing on the Retaining Ear and Enabling it to Spin Freely. 98-7913 Anti Scalp Wheel Spacer Fits Toro Late TITAN HD Models (1500, 2000, 2500 – Standard & My-Ride – Models with Tube Style Framing) – Late/Current 60″ Grandstand Standard Models – Current Grandstand 72″ HDX Models – Late ZMaster 2000 Models (Tube Style Framing) – Current/Late ZMaster 3000, 4000, 5000, 6000 7500, Revolution Models – Late ZMaster Z & 7000 Models – GroundMaster & Older Walk-Behind Models.

*Due to Variation Within Model Numbers/Series, please refer to the Images above; Product Specifications and to the Model Fit Chart below to ensure a correct fit and for an Accurate Break down of Specific Model Number Usage.

ASSOCIATED ANTI-SCALP WHEEL PARTS FOR PART NUMBER 98-7913 ONLY

CLICK ON THE ASSOCIATED PART NUMBER TO BE REDIRECTED

1. 323-23 – HEX HEAD BOLT (Retains the Anti-Scalp Wheel, Anti-Scalp Wheel Spacer and Spanner to Mower Deck) x1 Per Anti-Scalp Wheel
2. 98-7912 – ANTI-SCALP WHEEL SPANNER TUBE (Installed Through the Mower Deck Anti-Scalp Wheel and Anti-Scalp Wheel Spacer as well as Between the Dual Mower Deck Fastening Ears/Bracket – Enables the Fasteners Bolt/Nut to Be Firmly Tightened Without Bending the Mower Deck Anti-Scalp Wheel Fastening Ears/Bracket Against the Anti-Scalp Wheel) x1 Per Anti-Scalp Wheel
3. 98-7913 – ANTI-SCALP WHEEL SPACER TUBE (Installed Over the Anti-Scalp Wheel Spanner Tube and Against the Non-Molded Flange Side of the Anti-Scalp Wheel to Eliminate the Anti-Scalp Wheel from Moving Side to Side and Rubbing Against the Metal Anti-Scalp Wheel Fastening Ears/Brackets) x1 Per Anti-Scalp Wheel
4. 1-603299 – ANTI-SCALP WHEEL (Small Wheels Fastened to the Mower Deck and Aids in Helping the Mower Deck to Float Across Uneven Terrain, Helping to Eliminate Scalping) x? Quantity Varies Depending on Model/Series
5. 104-8301 – FLANGE LOCK NUT (Retains the Ant-Scalp Wheel, Anti-Scalp Wheel Spacer and Spanner to Mower Deck) x1 Per Anti-Scalp Wheel

Specification

Model Fit:

TITAN HD

48” TITAN HD 1500 & HD 2000 (PRE – Current IBEAM – Framing – Tube Framing Models Only) –
48″ Late Models / Tubed Framing –
(* Model Numbers 78450, 74465, 74460, 74453, 74450)

52” TITAN HD 1500 & HD 2000 (PRE – Current IBEAM – Framing – Tube Framing Models Only) –
52″ Late Models / Tubed Framing –
(* Model Numbers 74451, 74454, 74461, 74466)

60” TITAN HD 1500 & HD 2000 (PRE – Current IBEAM – Framing – Tube Framing Models Only) –
60″ Late Models / Tubed Framing –
(* Model Numbers 74452, 74462, 74463, 74467, 74480)

60” TITAN HD 2500 Series (PRE – Current IBEAM – Framing – Tube Framing Models Only) –
60”
Early Models Only – (* Model Numbers 74470, 74471, 74472, 78472)

GRANDSTAND

60” GRANDSTAND
–

(Standard)
–
(
* Model Numbers 74513, 74523, 74550, 74551, 74553, 74576, 74583, 79551, 79553)

72” GRANDSTAND
–

(HDX)
–
(
* Model Numbers
72517)

Z-MASTER

CURRENT/LATE MODELS

Z MASTER 3000 MODELS –
LATE MODELS –
(MODEL NUMBERS 72932, 72936, 72949, 72950, 72952, 72958, 72959)

Z MASTER 4000 MODELS –
CURRENT/LATE MODELS– Current IBEAM –
(MODEL NUMBERS 74000, 74002, 74004, 74010, 74015, 74020, 74022, 74024, 74035, 74050, 74052, 74054, 74055
)

Z MASTER 5000 MODELS –
CURRENT/LATE MODELS –
(MODEL NUMBERS 72904, 72906, 72907, 72908, 72910, 72911, 72912, 72915, 72918, 72921, 72922, 72923, 72924, 72930, 72943, 72945, 72951, 72953, 72955, 72956, 72957)

Z MASTER 6000 MODELS –
CURRENT/LATE MODELS –
(MODEL NUMBERS 72926, 72928, 72946, 72947, 72960, 72961, 72965, 72967, 72968, 72969, 72976, 72977, 72980, 72981, 72982, 72983)

Z MASTER 7500 MODELS –
CURRENT/LATE MODELS –
(MODEL NUMBERS 72027, 72028, 72029, 72030, 72065, 72074, 72076, 74028, 74029, 74060, 74064, 74072, 74074)

Z MASTER REVOLUTION MODELS –
CURRENT/LATE MODELS– Current IBEAM –
(MODEL NUMBERS 18748, 18752, 18760, 18765)

EARLY/LATE MODELS

48” Z Master 2000
(PRE – Current IBEAM – Framing – Tube Framing Models Only)

– (* Model Numbers 74141, 74143, 74145, 74490, 74491, 74492, 74493, 74494, 74495, 74496, 74497, 77248, 77260, 77280, 77282, 77284, 77287, 77290, 77293, 77299)

Z MASTER 3000 MODELS –
EARLY/LATE MODELS –
(MODEL NUMBERS 74949, 74950, 74952, 74953, 74954, 74955, 74956, 74957, 74958, 74959, 74990, 74994, 74996, 75932, 75934, 75936, 75990, 78953
)

Z MASTER 5000 MODELS –
EARLY/LATE MODELS –
(MODEL NUMBERS 74901, 74903, 74904, 74906, 74915, 74916, 74918, 74930, 74933, 74934, 74942,74943, 74944, 74945, 74991, 74995, 75930, 75951, 75955
)

Z MASTER 6000 MODELS –
EARLY/LATE MODELS –
(MODEL NUMBERS 74922, 74923, 74925, 74926, 74927, 74928, 74936, 74938, 74939, 74940, 74946, 74947, 74960, 74961, 74969, 74975, 74977, 74978, 74979, 74992, 74993, 74997, 74998, 75967, 75968, 78922, 78924, 78926, 78928
)

Z MASTER 7000 MODELS –
EARLY/LATE MODELS –
(MODEL NUMBERS 72266, 72267, 72274)

Z MASTER G3 MODELS –
EARLY MODELS –
(MODELS NUMBERS 74921, 74935, 74937, 74951)

Z MASTER Z MODELS
–
EARLY MODELS
–
(MODEL NUMBERS 74237, 74238, 74239, 74242, 74243, 74244, 74245, 74246, 74247, 74248, 74249, 74250, 74251, 74252, 74253, 74254, 74255, 74256, 74261, 74262, 74263, 74264, 74265, 74266, 74267, 74268, 74269, 74270, 74271, 74272, 74273, 74274, 74282, 74283, 74284, 74291, 74292, 74295, 74296, 74297, 74408, 74409, 74410, 74412, 74413, 74414, 74415, 74416, 74417, 74418, 74441, 74442, 74444, 74445, 74448, 74449, 79408, 79409)

GROUNDMASTER

GROUNDMASTER
–

(
* Model Numbers 30354, 30360, 30363, 30366, 30368, 30551, 30553, 30373, 30456, 30467, 30468, 30481, 30534, 30535, 30537, 30538, 30540, 30541, 30619, 31229, 31336, 31890, 31891, 31892, 31893, 31970, 31971, 31972, 31973, 31974, 31975)

OLDER WALK-BEHIND MODELS

OLDER WALK-BEHIND MODELS
–


(
* Model Numbers 30076, 30078, 30079,
30096, 30098, 30099, 30280, 30286, 30288, 30289, 30486, 30488, 30489, 30496, 30498,  30499, 38096, 39078, 39096, 39488, 39496, 39498)

BAGGER SYSTEMS

BAGGER SYSTEMS
–

(
* Model Numbers 78512)

ANT-SCALP KITS

ANTI-SCALP KITS
–

(
* Part Numbers 108-4140, 108-4141, 112-1792, 115-1015, 115-1016)
